组件名称

规格

处理器

6/7thGenerationIntel®Core™processors,LGA1151socket

芯片组

Intel® Q170 Chipset

系统内存

2*260-pin SODIMM up to 32GB, Dual Channel DDR4 1866/2133MHz

BIOS

InsydeSPI128Mbit

网络

1*Intel® I219LM PCIe with iAMT11.0 (10/100/1000Mbps)(only Core i7/i5 supports iAMT) 1*Intel® I211AT PCIe (10/100/1000Mbps)

背部I/O接口

以太网络

2*GbE (RJ-45)

USB

4*USB 3.0

显示

1*DP++

内部I/O接口

串行端口

2*RS-232(2.00mm pitch)

USB

4*USB 2.0 (2.00mm pitch)

音效

1*Audio (Line-out/Mic-in),1*Speaker (3W amplifier)

SATA

2*SATA 3.0 (up to 6Gb/s)

显示

1*LVDS LCD Panel Connector, 1*eDP

扩展槽

1*Full-size Mini PCIe(USB/PCIe/SATA, SATA by default) 1*Half-size Mini PCIe(USB/PCIe/SATA, Mini PCIe by default) 1*PCIe x16

显示

1*eDP:resolution up to 4096x2304@ 60Hz 1*LVDS:resolution up to 1920x1080 @ 60Hz 1*DP++:resolution up to 4096x2304@ 60Hz

音频

Realtek ALC888S-VD2-GR

温度

工作温度: -0 to 60°C, 存储温度:40 to 85°C

湿度

工作湿度:5 to 90% RH, 存储湿度:5 to 90% RH

尺寸

170mm (6.7")*170mm (6.7")
