处理器

CPU

Intel®H110

网络

2*RJ45, Intel i211AT GbE (10/100/1000 Mbps)

1*RJ45, Intel I219LM GbE (10/100/1000 Mbps)

内存

2*DDR4 2133MHz SO-DIMM, up to 32GB

显示

Dual Displays

1*VGA: max resolution up to 1920 x 1200

1*HDMI: max resolution up to 4096 x 2160

1*DP++: max resolution up to 4096 x 2304

储存

2*2.5" SATA 3.0 HDD/SSD Bay

1*M.2 2242 SSD slot

串口

4*232/422//485 auto-flow

2*RS232 (optional by internal pin head)

USB

4*USB3.0, 4*USB2.0

GPIO

1*16bit programmable GPIO (default 3.3V, 5V optional)

扩展插槽

1*Mini-PCIe slot (PCIe/SATA signal supported)

1*SIM 3G/4G SIM socket

电源

19-24V DC, 4-pin phoenix connector (9-36V DC optional with power board）

外形尺寸

200mm x 230mm x 78mm

工作环境

Temperature

工作温度:'-10°C~40°C (65W SSD )

-10°C~50°C (35W SSD)

0°C~30°C (HDD)

存储温度：-40~85°C

安装方式

桌面式 (Desk-Mount), 壁挂式 (Wall-Mount)
