处理器

CPU

6th Generation Intel® CoreTM Processors, BGA 1356

Intel® CoreTM i3-6100U Processor, Dual Core, 3M Cache, 2.3GHz, 15W

网络

1*Intel® I210AT PCIe (10/100/1000Mbps)

1*Intel® I219LM with iAMT11.0 PCIe (10/100/1000Mbps) (only Core i7/i5 supports iAMT)

内存

4GB Memory Onboard Dual Channel DDR4 2133MHz

显示

Dual Displays

1*HDMI HDMI: resolution up to 4096x2160 @ 24Hz or 2560x1600 @60Hz

1*VGA VGA: resolution up to 1920x1200 @ 60Hz

储存

1*2.5" SATA 3.0 Drive Bay

串口

2*RS-232/422/485 (DB-9, COM 1~2)

1*RS-232 (DB-9, COM 4, support 8-bit DIO by jumper setting)

1*RS-232 (DB-9, COM 3)

USB

4*USB 3.0 (type A)

DIO

1*8-bit DIO (DB-9)

扩展插槽

1*Full-size Mini PCIe (PCIe+USB)

1*Half-size Mini PCIe (USB+PCIe or USB+SATA, PCIe/SATA is selected by jumper setting, USB+SATA by default)

电源

15~36V DC-in

外形尺寸

181.6mm x 57mm x 118.4mm (W x H x D)

工作环境

Temperature

工作温度:-20~60°C (wide-temp SSD or mSATA-mini)

0~50°C (general SSD or mSATA-mini)

存储温度：-20°C~85°C

安装方式

Wall固定支架 - 支架与螺丝(标配)

VESA/DIN Rail固定支架 - 支架与螺丝(选配)
