Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

550

Contrast Ratio

33.3340277778

LCD Size

5.7”(4:3)

Max Resolution

640(W) x 480(H)

Environment

Humidity

10% to 95% (non-condensing)

IP Level

Front IP 65

Operating Temperature

-10°C~50°C (14°F~122°F)

Safety & EMC

CE & FCC Class A certified

Storage Temperature

-20°C~60°C (-4°F~140°F)

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini slot (with mSATA, PCIe/USB signal)

I/O Interface

I/O Ports and Switches

1 x RJ-45 LAN port

1 x RS-232 COM port (DB-9 connector)

(RI/5V/12V)

1 x RS-422/485

2 x USB 3.0

2 x USB 2.0

1 x 9 V~30 V DC lockable DC jack (2-pin)

1 x Audio port (line-out)

1 x Power switch

RAM

2GB DDR3L 1600MHz on-board RAM (system max. 4GB, by MOQ=300pcs)

LCD

LCD Color

262K

Pixel Pitch (mm)

0.18mm x 0.18mm

Viewing Angle (H-V)

160° / 140°

Physical Characteristics

Color

Black C

Construction

Aluminum front bezel

Cutout Dimensions

157.5 x 115.4

Dimensions (LxWxH) (mm)

136.4 x 178.5 x 56.3

Mounting

Stand, panel mount, rack mount, VESA 75x75

Power

Power adapter

9V~30VDC

System

CPU

Intel® Celeron® N2807 dual-core processor, 1.58GHz

SSD

mSATA

Touch

Touch Controller

PenMount DMC9000

Touch Screen

4-wire resistive type flat touch window

Weight

Weight

0.89Kg

I/O Interface

I/O Interface

1 x AT/ATX Switch

2 x USB3.0

2 x USB2.0

1 x Reset Button

1 x Power In((9-30V Lockable power jack))

1 x RS-232(((DB-9)))

1 x Power Switch

1 x LAN((RJ-45))

1 x Audio(((line-out)))

1 x RS-422/485
