Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

800

Contrast Ratio

600:1

LCD Size

6.5”(4:3)

Max Resolution

640 (W) x 480 (H)

Environment

Humidity

10% to 95% (non-condensing)

IP Level

IP 65 compliant front panel

Operating Temperature

-20°C ~ 60°C (with air flow)

Storage Temperature

-20°C ~ 70°C

I/O Interface

I/O Ports and Switches

1 x VGA (DB-15)

1 x DVI

1 x USB 2.0 (touch)

1 x RS-232 (reserved for resistive touch ATO)

1 x Lockable 12V DC jack

LCD

LCD Color

16.2M

Pixel Pitch (mm)

0.207 x 0.207

Viewing Angle (H-V)

160° / 140°

Physical Characteristics

Cutout Dimensions

180 x 140

Dimensions (LxWxH) (mm)

191.8 x 154.36 x 42.88

Power

Power adapter

12V DC

Touch

Touch Controller

Penmount 6000

Touch Screen

5-wire resistive single touch window

Weight

Weight

1.1/2.6 Kg
