Spec Item

Description

Communication

Bluetooth

V4.1 (M.2 2230 A-E key module)

Wi-Fi

IEEE 802.11 a/b/g/n/ac 2T2R module

Environment

Humidity

10% to 95% (non-condensing)

IP Level

IP 65 compliant front panel

Operating Shock

Operating Shock: 5G peak acceleration (11ms duration)

Non-Operating Shock: 15G peak acceleration (11ms duration)

Operating Temperature

0°C~40°C

Operating Vibration

1G

Storage Temperature

-20°C~60°C

Function Key

Function Key

1 x LCD on/off

1 x Brightness up

1 x Brightness down

1 x Volume up

1 x Volume down

1 x Touch lock button for cleaning

Combinations:

1 x Lock/Unlock OSD

1 x Power on/off

I/O Interface

Audio

2 x 2W speaker

Expansion

1 x PCIe Mini reserved

I/O Ports and Switches

1 x RJ-11 for barcode module (1D/2D)

4 x USB 2.0 (2 for side)

4 x USB 3.0 port

1 x HDMI output

2 x GbE LAN port

1 x RS-232/422/485

1 x 12~28V DC jack

LCD

Backlight MTBF

30000 (LED backlight)

Brightness (cd/m2)

350

Contrast Ratio

1000:1

LCD Color

16.7M colors (RGB 6-bit)

Pixel Pitch (mm)

0.264 (H) x 0.264 (V)

Resolution

1280 (W) x 1024 (H)

Size

17” (5:4)

Viewing Angle (H-V)

170°(H) / 160°(V)

Other Features

Ambient Light Sensor

Ambient light sensor for panel brightness adjustment

Camera

2-megapixel CMOS front-facing

Microphone

digital microphone

RFID Reader

Optional: Mifare 13.56 MHz card reader

System Cooling

Fanless

Physical Characteristics

Construction

ABS+PC plastic with anti-bacterial material

Dimensions (LxWxH) (mm)

435 x 376 x 64.5

Mounting

Wall, Stand and Arm VESA 100mm x 100mm / 75mm x 75mm

Power

Input

12V~28V DC input

Power adapter

120W medical power adapter: Input: 100V~240V AC, Output: 19V DC

System

Cooling method / System Fan

Fanless

CPU

Intel® Skylake-ULT platform Core™ i5-6300U and Celeron® 3955U

Memory Max.

Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs (system max. 32GB)

Storage

2 x 2.5” SATA 6Gb/s HDD bay

1 x mSATA reserved (M.2 interface)

Touch

Touch Controller

ILITEK

Touch Screen

Projected capacitive type with USB interface

Surface Hardness: 6H

Weight

Weight

5.8 Kg

LED Function

LED Function

RFID indicator LED
