Spec Item

Description

Communication

Wi-Fi

IEEE 802.11b/g/n (internal Mini PCI) Telec certified

Dimensions

Dimensions

470 x 383 x 72(WxHxD) (mm)

Environment

Operating Temperature

0°C~50°C

Storage Temperature

-20°C~60°C

I/O Interface

1 x RS-232 COM Port

1 x RS-232/422/485 COM Port

2 x RJ-45 for Giga LAN

4 x USB 2.0

1 x Power Switch

1 x Reset Button

1 x Audio Port (Line-out)

1 x VGA

1 x Power Jack

1 x HDMI Port

I/O Ports and Switches

RAM

Two 204-pin 800/1066MHz DDR3 dual-channel SO-DIMMs supported (Max. 8GB)

LCD

Backlight MTBF

50000 (LED backlighting) or 30000

Brightness (cd/m2)

350

Contrast Ratio

1000:1

LCD Color

16.7M

Pixel Pitch (mm)

0.294 (H) x 0.294 (V)

Resolution

1280 x 1024

Size

19"

Viewing Angle (H-V)

170º/160º

Power

Power Requirement

12 VDC

Storage

Storage

1 x 2.5” SATA HDD bay

System

Chipset

Intel® HM55

CPU

Intel® Core™ i7/i5/i3/Celeron® Processor

Weight

Weight

6.2Kg

I/O Interface

I/O Interface

1 x Reset Button

4 x USB 2.0

1 x RS-422/485

1 x RS-232

1 x Power Switch

2 x LAN(GbE LAN (RJ-45))

1 x HDMI

1 x Audio((line-out))

1 x VGA

1 x DC Input Jack
