Spec Item

Description

Environment

Operating Temperature

0°C~50°C

Storage Temperature

-20°C ~ 60°C

LCD

Backlight MTBF

50000 hrs (LED backlighting)

Brightness (cd/m2)

450

Contrast Ratio

700:1

LCD Color

16.2M

Pixel Pitch (mm)

0.297(H) x 0.297(V)

Resolution

1024 x 768

Size

15”

Viewing Angle (H-V)

160º/150º

Physical Characteristics

Dimensions (LxWxH) (mm)

394 x 309 x 66

Power

Power Requirement

12VDC

System

Chipset

Intel® HM55

CPU

Intel® Core™ i7/i5/i3/Celeron® Processor

Memory Max.

Two 204-pin 800/1066MHz DDR3 dual-channel SO-DIMMs supported (Max. 8GB)

Storage

1 x 2.5” SATA HDD bay

Touch

Touch Screen

Resistive Type 5-Wire

Weight

Weight

5.8 Kg

I/O Interface

I/O Interface

1 x HDMI

1 x VGA

2 x LAN(Gbe(RJ-45))

1 x DC Input Jack

1 x Reset Button

4 x USB 2.0

1 x Power Switch

1 x RS-232

1 x Line out

1 x RS-422/485
