Spec Item

Description

Communication

Wi-Fi

IEEE 802.11a/b/g/n/ac

Dimensions

Dimensions

396 x 250 x 53

Environment

Operating Temperature

-20°C~50°C

Storage Temperature

-20°C~60°C

I/O Interface

I/O Ports and Switches

1 x RS-232 COM port (RJ-45 connector)

1 x RS-232/422/485 COM port

(DB-9 connector) (RI/5V/12V)

2 x USB 2.0

2 x USB 3.0

2 x GbE LAN

1 x Power switch

RAM

One 204-pin 1333MHz single-channel DDR3L SDRAM,2GB pre-installed (system max. 8GB)

LCD

Backlight MTBF

50000 (LED backlight panel)

Brightness (cd/m2)

400

Contrast Ratio

500:1

LCD Color

16.2M

Pixel Pitch (mm)

0.240 (H) x 0.240 (V)

Resolution

1366 x 768

Size

15.6"

Viewing Angle (H-V)

170°/160°

Other Features

Camera

2-megapixel with low light function

Microphone

digital microphone

Power

Power Requirement

9~30 VDC

Storage

Storage

mSATA , 2.5” SATA 3Gb/s HDD bay

System

Chipset

N/A

CPU

Intel® Celeron® J1900 (quad core, 2 GHz)

Touch

Touch Controller

PenMount DMC9000/ EETI EXC7200

Touch Screen

5-wire resistive type with RS-232 interface / projected capacitive type with USB interface

Weight

Weight

3.3Kg

I/O Interface

I/O Interface

1 x Power Switch

2 x LAN(GbE LAN)

2 x USB 3.0

1 x Audio((line-out))

1 x AT/ATX switch

1 x Reset Button

1 x RS-232((RJ-45 connector))

1 x RS-422/485(COM port(DB-9 connector) (RI/5V/12V))

2 x USB 2.0

1 x DC Input Jack(9-30V lockable power jack)
