Spec Item

Description

Communication

Wi-Fi

IEEE 802.11a/b/g/n/ac

Dimensions

Dimensions

191 x 127 x 43

Environment

Operating Temperature

-20°C~50°C

Storage Temperature

-20°C~60°C

I/O Interface

I/O Ports and Switches

2 x RS-232 COM port (DB-9 connector)

2 x USB 3.0

2 x GbE LAN

1 x Power switch

1 x Reset button

1 x AT/ATX switch

1 x 9-30V Lockable power jack

RAM

2GB DDR3L onboard RAM/4GB DDR3L onboard RAM

LCD

Backlight MTBF

20000 (LED backlight panel)

Brightness (cd/m2)

500

Contrast Ratio

700:1

LCD Color

16.2M

Pixel Pitch (mm)

0.0635 (H) x 0.1905 (V)

Resolution

1024 x 600

Size

7"

Viewing Angle (H-V)

150º/145º

Other Features

Camera

N/A

Microphone

N/A

Power

Power Requirement

9~30 VDC

Storage

Storage

mSATA

System

CPU

Intel® Celeron® N2807 (dual core, 1.58 GHz)

Touch

Touch Controller

EETI EXC3160

Touch Screen

projected capacitive type

Weight

Weight

0.73Kg

I/O Interface

I/O Interface

2 x RS-232(COM port (DB-9 connector))

1 x Reset Button

1 x Power Switch

2 x LAN

1 x AT/ATX switch

2 x USB 3.0

1 x DC Input Jack(9-30V Lockable power jack)
