Spec Item

Description

Display

Backlight MTBF(hrs)

30000

Brightness(cd/m2)

250

Contrast Ratio

1000:1

LCD Size

21.5”(16:9)

Max Resolution

1920 (W) x 1080 (H)

Environment

Humidity

10% to 95% (non-condensing)

IP Level

IP 65 compliant front panel

Operating Temperature

-10°C~50°C (14°F~122°F)

Storage Temperature

-20°C~60°C (-4°F~140°F)

I/O Interface

I/O Ports and Switches

2 x RJ-45 LAN Port

2 x USB 3.0

4 x USB 2.0

1 x HDMI output

4 x RS-232

1 x RS-422/485

1 x VGA output

1 x AC/DC power plug (DC model is by build to order manufacturing)

1 x AT/ATX switch

1 x Clear CMOS

1 x Reset button

1 x Power switch

LCD

LCD Color

16.7M

Pixel Pitch (mm)

0.25 x 0.25

Viewing Angle (H-V)

170° / 160°

Physical Characteristics

Cutout Dimensions

341 x 536

Dimensions (LxWxH) (mm)

350.4 x 550.4 x 71.7

Power

Power Supply

AC input ATX power supply

220W power supply

Input: 90VAC-264VAC, 50/60Hz

Output (max.): 3.3V@10A, 5V@14A, 12V@14A, -12V@0.3A

Touch

Touch Screen

2-point projected capacitive touch window (EETI EXC7200), 6H

Weight

Weight

10.1/14.4
