Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

350

Contrast Ratio

1000 : 1

LCD Size

19"

Max Resolution

1280(W) x 1024(H)

Environment

Operating Temperature

-10°C ~ 50°C

Storage Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

Either 1 x PCI slot or 1 x PCIe slot

1 x PCIe Mini card

Other Features

System Cooling

Active with Fan

Physical Characteristics

Cutout Dimensions

450 x 363

Dimensions (LxWxH) (mm)

482 x 399 x 115

System

Chipset

Intel® H61

CPU

2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor, up to TDP 65W

HDD

1 x 2.5” SATA HDD bay with anti-shook

SSD

SSD CF Type II, mSATA (SATA2 signal)

Weight

Weight

12.6 kg / 18.2 kg

I/O Interface

I/O Interface

1 x Line in

4 x LAN((RJ-45) x 2/SFP fiber LAN x 2)

1 x AT/ATX Switch

1 x VGA

2 x USB3.0

4 x USB2.0

1 x RS-422/485

1 x Line out

1 x Power Switch

4 x RS-232
