规格

描述

显示

背光 MTBF(hrs)

70000

亮度(cd/m2)

450

对比度

800:1

LCD 尺寸

15”

最大分辨率

1024x768

运行环境

湿度

5% ~95%, non-condensing

IP 等级

IP66 compliant front panel

操作温度

-20°C~ 50°C (with SSD and TDP 65W processor)

-20°C ~ 40°C (with HDD or add-on cards without fan)

安全和EMC

CE, FCC, CCC

存储温度

-30°C ~ 60°C

扩展插槽

扩展插槽

2 x PCIe 3.0 by 8 (by 16 slot)

2 x PCIe 3.0 by 4 ( maximum card size supported: 68 mm x 167 mm)

规格

规格

8th Genertion Intel CoreTM i7/i5/i3 porcessors in the LGA 1151

Intel® 300 Series Chipsets Q370

I/O 接口

以太网

Intel® I211AT Ethernet controllers

其它特征

TPM

Support(2x10pin, P=2.54mm)

物理特性

颜色

Front frame: Cyan-blue (PSM 296C); Others: Black C

切口尺寸

361.1x285.6

尺寸 (LxWxH) (mm)

378.5x303x118

安装

Panel/Rack mount

净重

7.3

电源

电源

AC input ATX power supply

1. 250 W power supply

- Input: 115VAC~230VAC, 50/60Hz

- Output (max.): 3.3V@12A, 5V@14A, 12V@25A, -12V@0.3A,+5Vsb@3A

2. 350 W power supply (Build to Order)

- Input: 115VAC~264VAC, 50/60Hz

- Output (max.): 3.3V@14A, 5V@16A, 12V@29A, -12V@0.3A,+5Vsb@3A

- Efficiency: Full load (100%) 87%, Typical load (50%) 90%, Light load (20%) 87%

存储

存储

4 x Hot-swappable SATA 6G/s HDD/SSD bay (support RAID 0/1/5/10)

2 x M.2 M-key (2280, PCIe 3.0 x4), support NVMe SSD

系统

芯片组

Intel® 300 Series Chipsets Q370

散热方式 / 系统风扇

System fan

CPU

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU

最大内存

Two 288-pin 2666/2400 MHz dual-channel unbuffered DDR4 SDRAM DIMM slots (system max. 64 GB)

触摸

触摸控制器

EETI EXC3188

触摸屏

10-point Projected capacitive touch window, 6H (Anti-UV, Anti-glare Surface)

I/O 接口

I/O 接口

1 x AT/ATX switch

1 x HDMI

2 x LAN

1 x Line out

1 x Mic

1 x Power Switch

1 x Reset Button

2 x RS-232

6 x USB 3.0
