Spec Item

Description

Form factor

SBC Form Factor

Intel® Celeron® J1900 processor (2 GHz, quad-core, 2 MB cache, TDP=10W)

System

Cooling method / System Fan

Fanless

Chipset

SoC

Memory Max.

1 x 204-pin 1066/1333 MHz single-channel DDR3L SO-DIMM (system max. 8 GB)

Drive Bays

1 x 2.5' SATA 3Gb/s HDD Bay

Storage

1 x 2.5' SATA 3Gb/s HDD Bay

I/O Interface

Display

1 x VGA

Audio

1 x Line out

I/O Interface

1 x VGA

3 x USB 2.0

1 x USB 3.0

3 x RS-232

1 x RS-422/485

1 x PCIe GbE by Intel I210

1 x PCIe GbE by Intel I211

1 x Line out

Digital I/O

8-bit digital I/O

Power

Input

3-pin terminal: 9 V~36 V DC

Power consumption

12V@1.45A (with Intel® Celeron® J1900 CPU and one 8 GB 1333 MHz DDR3 memory)

Environment

Operating Temperature

-20°C ~ 60°C with air flow (SSD)

Dimensions

Dimensions

229 x 64 x 132

Weight

Weight

2.1 kg / 3.9 kg

Expansion Slots

Expansion Slots

1 x Half-size PCIe Mini card (only for iRIS)

Option

iRIS

1 x iRIS-1010-R10 (optional purchase)
