Spec Item

Description

Form factor

SBC Form Factor

Intel® mobile Core™ i5-4400E with AMT 9.0 support (up to 2.7GHz, dual-core, 3MB cache, TDP=37W)

Intel® mobile Celeron® 2000E (up to 2.2GHz, dual-core, 2MB cache, TDP=37W)

System

Cooling method / System Fan

Fanless

Chipset

Intel® QM87

Memory Max.

One 204-pin 4GB DDR3 SO-DIMM pre-installed (system max: 8GB)

Drive Bays

2 x 2.5” SATA 6Gb/s HDD/SSD drive bay

I/O Interface

Display

2 x HDMI, 1 x VGA

Audio

1 x Line-out, 1 x Mic-in

I/O Interface

2 x USB 3.0

4 x USB 2.0

2 x RJ-45

2 x RS-232

Serial

2 x RS-232

Power

Input

DC jack: 12 V DC

3-pin terminal: 9 V~36 V DC

Power consumption

12 V@4.6 A (Intel® mobile Core™ i5-4400E with 4GB 1333MHz DDR3 memory)

Environment

Operating Temperature

-20°C ~60°C with air flow (SSD)

Humidity

10% ~ 95%, non-condensing

Dimensions

Dimensions

265 x 134 x 56.7

Weight

Weight

2.4 kg/4.2 kg

Color

Color

Silver

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini (supports mSATA, SATA 6Gb/s signal only)

1 x Half-size PCIe Mini (only for iRIS-1010)

Option

iRIS

1 x iRIS-1010 (optional)
