Spec Item

Description

Dimensions

Dimensions

170mm x 170mm

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219LM with (Intel® AMT 11.0 support)

LAN2: Intel® I211 PCIe controller with NCSI support

Expansion

1 x PCIe x16 slot

1 x Full-size PCIe Mini card slot (support mSATA)

1 x M.2 2230 (A key)

1 x Half-size PCIe Mini card slot

I/O Interface

I/O Interface

1 x SMBus(1 x 4pin)

1 x I²C(1 x 4pin)

4 x Internal USB 2.0(2 x 4 pin,p=2.0)

3 x Internal RS-232(1 x 9 pin,p=1.25)

2 x Internal RS-232/422/485(1 x 9 pin,p=1.25)

1 x KB/MS(1 x 6 pin,p=2.0)

4 x SATA 6Gb/s(RAID 0/1/5/10 support)

System

Chipset

Intel® CM236

CPU

6th generation Intel® processor

Intel® Xeon® processor E3-1505M v5 (up to 3.7GHz, quad-core, 8M Cache, TDP=45W)

Intel® Xeon® processor E3-1505L v5 (up to 2.0GHz, quad-core, 8M Cache, TDP=25W)

Intel® Core™ i3-6102E processor (up to 1.90GHz, dual-core, 3M cache, TDP=25W)

Intel® Celeron® processor G3902E (up to 1.60GHz, dual-core, 2M cache, TDP=25W)

Memory Max.

Two 260-pin 2133/1866 MHz dual-channel DDR4 ECC and non-ECC unbuffered SDRAM SO-DIMMs support up to 64GB

Weight

Weight

900g / NW: 450g
