Spec Item

Description

Display

Display Output

Triple independent display

1 x VGA (up to 1920 x 1080@60Hz)

1 x DP++ (up to 4096 x 2304@60Hz)

1 x HDMI (up to 4096 x 2304@30Hz)

1 x internal Displayport (up to 4096 x 2304@60Hz)

System

CPU

LGA1151 socket supports 8th/9th generation Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor

Chipset

Intel® Q370

Memory Max.

Four 288-pin 2666/2400 MHz Dual-Channel DDR4 SDRAM Unbuffered DIMMs supported up to 64GB

I/O Interface

Ethernet

LAN1 : Intel® I219LM PCIe controller with AMT 11.0 support

LAN2: Intel® I211AT PCIe controller

Digital I/O

8-bit digital I/O (2x5 pin)

Audio

Realtek ALC662 HD Audio Codec supports 5.1 channel

3 x Audio jacks (line-out, line-in, mic-in) on rear IO

1 x Front Audio (2x5 pin)

I/O Interface

I/O Interface

1 x Front panel(2x7 pin, power LED, HDD LED, speaker, power button, reset button)

3 x Internal RS-232(2x5 pin, P=2.54)

2 x Internal RS-232/422/485(2x5 pin, P=2.54)

4 x Internal USB 2.0(2x4 pin, P=2.0)

2 x Internal USB 3.0(2x10 pin, P=2.0)

1 x I²C(1x4 pin)

1 x KB/MS

1 x KB/MS(1x6 pin)

2 x LAN LED(1x2 pin)

1 x RS-232

6 x SATA 6Gb/s(RAID 0/1/5/10 supported)

1 x SMBus(1x4 pin)

4 x USB 3.0

2 x USB2.0

Power

Power consumption

3.3V@1.65A, 5V@3.4A, 12V@8.58A, 5VSV@3.4A (Intel® Core® i7-8700K up to 4.60 GHz CPU with 32GB 2600MHz DDR4 memory)

Power Supply

ATX/AT Power Supply

Environment

Operating Temperature

-20ºC ~ 60ºC

Humidity

5% ~ 95%, non-condensing

Storage Temperature

-30°C ~ 70°C

Dimensions

Dimensions

244mm x 305mm

Weight

Weight

GW:1200g, NW: 700g

Expansion Slots

Expansion Slots

2 x PCIe x8

3 x PCIe x4

2 x PCI

1 x M.2 M Key (2280, PCIe x2 only)

1 x M.2 A key (2230, PCIe x1 & USB 2.0)
