Spec Item

Description

Dimensions

Dimensions

244mm x 305mm

Display

Display Output

Triple independent display

1 x VGA (up to 1920x1200@60 Hz)

1 x DVI-D (up to 2560x1600@60Hz)

1 x HDMI 2.0 (up to 4096x2160@60Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 4096x2304@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (support mSATA)

2 x PCI slot

2 x PCIe x 8 slot (Gen3)

3 x PCIe x 4 slot (Gen3)

I/O Interface

Audio

Realtek ALC662 HD codec supports 5.1-channel

3 x Audio jacks (line-out, line-in, mic-in) on rear IO

1 x Front audio (2x5 pin)

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219LM with Intel® AMT 11.0 support

LAN2: Intel® I210AT PCIe controller

I/O Interface

I/O Interface

2 x Internal RS-232/422/485

1 x KB/MS

1 x Internal USB 3.0

1 x LPT

4 x Internal RS-232

5 x Internal USB 2.0

Option

iRIS

1 x iRIS-2400 slot

Power

Power consumption

3.3V@1.65A, 5V@3.4A, 12V@8.58A, 5VSB@3.4A (Intel® Core™ i7 6700K 4.0GHz CPU with 32 GB (four 4 GB) 2133 MHz DDR4 memory)

System

Chipset

Intel® Q170

CPU

LGA 1151 socket supports Intel® 6th/7th generation Core™ i7/i5/i3, Pentium® or Celeron® processor

Memory Max.

Four 288-pin 2133 MHz dual-channel DDR4 SDRAM unbuffered DIMMs support up to 64 GB
