Spec Item

Description

Display

Display Output

Dual independent display

1 x DVI-I (up to 2560x1200@60Hz)

1 x HDMI 1.4 (up to 4096x2160@24Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 4096x2304@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (support mSATA)

1 x PCIe x16 slot (Gen3)

6 x PCI slot

I/O Interface

Audio

Realtek ALC662 HD codec supports 5.1-channel 3 x Audio jacks (line-out, line-in, mic-in) on rear IO 1 x Front audio (2x5 pin)

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219V PHY

LAN2: Intel® I211 PCIe controller

I/O Interface

I/O Interface

2 x Internal RS-232

RS-422/485((1 x 4 pin, P=2.0, colay with COM4))

1 x LPT((2 x 13 pin, P=2.54))

4 x SATA 6Gb/s((support hot plug))

1 x KB/MS((1 x 6 pin))

1 x I²C((1 x 4 pin))

1 x SMBus((1 x 4 pin))

1 x LPT((2 x 13 pin, P=2.54))

3 x Internal USB 2.0

2 x Internal RS-232/422/485((2 x 5 pin, P=2.54, colay with COM5,6))

Power

Power consumption

3.3V@1.53A, 5V@2.95A, 12V@8.38A, 5VSB@3.2A (Intel® Core™ i7 6700K 4.0GHz CPU with 16GB (two 8GB) 2133 MHz DDR4 memory)

Power Supply

ATX/AT Power Supply

System

Chipset

Intel® skylake H110

CPU

LGA 1151 socket supports Intel® 6th/7th generation Core™ i7/i5/i3, Pentium® or Celeron® processor

Memory Max.

Two 288-pin 2133 MHz dual-channel DDR4 SDRAM unbuffered DIMMs support up to 64 GB

Weight

Weight

GW:1200g, NW: 700g
