显示

显示输出

1 x VGA (up to 1920x1200@60 Hz)

系统

CPU

LGA2066 socket supports Intel® Xeon W processor

芯片组

Intel® C422

最大内存

Four 288-pin Dual-Channel DDR4 ECC RDIMM/LRDIMM supported up to 256GB

CPU 插槽

LGA2066

I/O 接口

以太网

LAN1: 1 GbE NIC: Intel® i210-AT with NCSI support

LAN2: 10 GbE NIC: Aquantia AQC107

音频

Support 7.1 channel HD audio by IEI AC-KIT-892HD kit

扩展

1 x M.2 M key 56 lanes PCIe signal via golden finger

I/O 接口

I/O 接口

2 x Ethernet

1 x Front panel

2 x Internal RS-232

2 x Internal USB 2.0

2 x LAN LED

8 x SATA 6Gb/s

2 x USB 2.0

4 x USB 3.0

运行环境

操作温度

-20°C ~ 40°C

湿度

5% ~ 95%, non-condensing

可选

iRIS

Yes

存储

存储

8 x SATA (SATA 6Gb/s) via mini SAS HD(SFF-8643)

尺寸

尺寸

338.58 mm x 150.5 mm

看门狗计时器

看门狗计时器

Software programmable support 1~255 sec. system reset

BIOS

BIOS

AMI UEFI BIOS
