Spec Item

Description

Display

Display Output

1 x VGA (2560x1600) (via reserved pin)

1 x DDI (DP/HDMI, max. resolution 2560x1600/1920x1080)

1 x eDP

nvironment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Ethernet

Intel® I210-AT GbE controller (Intel® I210-IT GbE controller with W2 sku)

Expansion

3 x PCIe x1 signal to baseboard

I/O Interface

I/O Interface

1 x Internal USB 3.0

4 x Internal USB 2.0

Power

Power consumption

12V@0.43A, Vcore_12V@0.9 A (Intel® Atom™ E3845 CPU, 2GB 1333 MHz DDR3Lmemory)

System

CPU

Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W)

Memory Max.

2GB soldered down 1066/1333 MHz DDR3L memory (up to 8GB)

Storage

2 x SATA 3Gb/s signal to baseboard Optional soldered down SSD up to 64GB (SATA port 1)
