Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

VGA integrated in AMD Geode™ LX 800

24-bit TTL

18-bit single-channel LVDS

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

0°C ~ 60°C

Expansion Slots

Expansion Slots

1 x PC/104

I/O Interface

Audio

Realtek ALC203 with AC`97 codec

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN: 10/100Mbps RTL8100C Ethernet Controller

I/O Interface

I/O Interface

4 x USB 2.0

6 x Internal RS-232

1 x RS-232

1 x Internal RS-232/422/485

Power

Power consumption

5V@1.33A (AMD Geode™ LX 800 with one 1GB 400MHz DDR memory)

Storage

Storage

1 x CF Type II

1 x IDE (2x22 pin, P=2.0)

System

Chipset

AMD CS5536

CPU

AMD Geode™ LX 800 (500MHz)

CPU Socket

On Board

Memory Max.

One 200-pin 400/333MHz DDR SDRAM SODIMM slot support up to 1GB

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
