Part Number

PCI-1758UDIO-AE

PCI-1758UDI-AE

PCI-1758UDO-AE

General

Power Consumption

Typical: 5 V @ 1.1 A, Max.: 5 V @ 2.2 A

Typical: 5 V @ 1.1 A, Max.: 5 V @ 2.2 A

Typical: 5 V @ 1.1 A, Max.: 5 V @ 2.2 A

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

175 x 100 mm (6.9" x 3.9")

175 x 100 mm (6.9" x 3.9")

175 x 100 mm (6.9" x 3.9")

Bus

PCI

PCI

PCI

I/O Connectors

MINI-SCSI HDRA-E100 Female

MINI-SCSI HDRA-E100 Female

MINI-SCSI HDRA-E100 Female

Operating Temperature

0 ~ 60°C (32 ~ 140°F)

0 ~ 60°C (32 ~ 140°F)

0 ~ 60°C (32 ~ 140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Isolated Digital I/O

Input Channels

64

128

-

Input Range

5 ~ 25 VDC

5 ~ 25 VDC

-

Output Channels

64

-

128

Output Ranges

5 ~ 40 VDC

5 ~ 40 VDC

5 ~ 40 VDC
