Part Number

PCI-1752U-BE

PCI-1752USO-BE

General

Power Consumption

Typical: 5 V @ 230 mA, Max.: 5 V @ 500mA

Typical: 5 V @ 230 mA, Max.: 5 V @ 500mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

175 x 100 mm (6.9" x 3.9")

175 x 100 mm (6.9" x 3.9")

Bus

PCI

PCI

I/O Connectors

100-pin SCSI-II female

100-pin SCSI-II female

Operating Temperature

0 ~ 60°C (32 ~ 140°F)

0 ~ 60°C (32 ~ 140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Isolated Digital I/O

Output Channels

64

64

Output Ranges

5 ~ 40 VDC

5~40 VDC (Source)
