Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

VGA (up to 2048x1536@60Hz)

18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to

1920x1200@60Hz)

iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 2560x1600@60 Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

0°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (supports mSATA co-lay SATA port 2)

I/O Interface

Audio

Realtek AL892 HD Audio codec

1 x S/PDIF by 4-pin (1x4) header for digital audio

1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I210-AT PCIe controller with NCSI support

LAN2: Intel® I211-AT PCIe controller

I/O Interface

I/O Interface

2 x Internal RS-232

1 x RS-232

2 x USB 3.0

1 x RS-422/485

4 x Internal USB 2.0

Option

iRIS

1 x iRIS-1010 slot

Power

Power consumption

+12V@2.12A (AMD GX-415GA 1.5GHz CPU with one 4GB 1333 MHz DDR3 memory)

Storage

Storage

2 x SATA 3Gb/s with 5V SATA power connector

System

CPU

AMD® Embedded G-Series SoC

GX-415GA on-board SoC (1.5GHz, quad-core, 2MB cache, TDP=15W)

GX-210HA on-board SoC (1.0GHz, dual-core, 1MB cache, TDP=9W)

GX-420CA on-board SoC (2.0GHz, quad-core, 2MB cache, TDP=25W)

GX-217GA on-board SoC (1.65GHz, dual-core, 1MB cache, TDP=15W)

CPU Socket

On Board

Memory Max.

One 204-pin 1600/1333 MHz dual-channel DDR3 & DDR3L SDRAM SO-DIMM slot supports up to 8GB

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset
