Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

Dual independent dispaly

VGA (up to 2560x1600@60Hz)

18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-40°C ~ 85°C

Expansion Slots

Expansion Slots

2 x Full-size PCIe Mini card slot (one with SIM holder)

I/O Interface

Audio

Realtek ALC662 HD Audio codec

1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I210-IT PCIe controller

LAN2: Intel® I210-IT PCIe controller

I/O Interface

I/O Interface

1 x USB 2.0

1 x USB 3.0

1 x Internal RS-232

4 x Internal USB 2.0

1 x RS-232

Power

Power consumption

12V@1.32A (Intel® Atom™ processor E3845 with on-board 2 GB 1333 MHz DDR3L

memory)

Storage

Storage

2 x SATA 3Gb/s with 5V SATA power connector (no RAID)

1 x mSATA colay SATA2

System

CPU

Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W)

Intel® Atom™ E3827 on-board SoC (1.75GHz, dual-core, 1MB cache, TDP=8W)

Intel® Atom™ E3826 on-board SoC (1.46GHz, dual-core, 1MB cache, TDP=7W)

Intel® Atom™ E3825 on-board SoC (1.33GHz, dual-core, 1MB cache, TDP=6W)

Intel® Atom™ E3815 on-board SoC (1.46GHz, single-core, 512KB cache, TDP=5W)

Memory Max.

4 GB solder-down 1066/1333 MHz DDR3L memory (for E3845)

2 GB solder-down 1066/1333 MHz DDR3L memory (for E3825)

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
