规格

描述

显示

显示

Dual display supported

1 x VGA (Resolution: 2560x1600@60Hz)

1 x dual channel 24bit LVDS connector

(1920x1200@60Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 2560x1600@60Hz)

系统

CPU

Intel® Atom™, Celeron® SoC

芯片组

Intel® Atom™/Celeron® on-board SoC

最大内存

One 204-pin 1066/1333 MHz single-channel DDR3L SO-DIMM slot supports up to 8 GB (J1900, N2930, E3845, E3827, E3826) or 4 GB (N2807, E3825, E3815)

I/O 接口

I/O 接口

3 x RS-232

1 x RS-422/485

1 x USB 3.0

5 x USB 2.0

1 x PS/2 KB/MS

以太网

LAN1: IntelR I210-AT PCIe controller with NCSI support

LAN2: IntelR I211-AT PCIe controller

数字 I/O

8-bit digital I/O (4-bit input / 4-bit output)

音频

Realtek ALC662 HD Audio codec

I/O 接口

I/O 接口

2 x Internal RS-232

4 x Internal USB 2.0

3 x RS-232

1 x RS-422/485

5 x USB 2.0

1 x USB 3.0

电源

功耗

12V@1.45A (IntelR CeleronR Processor J1900 CPU, with 8GB 1333 MHz DDR3L memory)

运行环境

操作温度

-20¢XC ~ 60¢XC

湿度

5% ~ 95%, non-condensing

存储

存储

2 x SATA 3Gb/s with 5V SATA power connector (no RAID)

扩展插槽

扩展插槽

1 x Full-size PCIe Mini card slot (supports mSATA co-lay SATA port 2)

1 x Half-size PCIe mini card slot

看门狗计时器

看门狗计时器

Software programmable and supports 1~255 sec. system reset

CPU 散热器

CPU 散热器

N/A
