Spec Item

Description

CPU Cooler

CPU Cooler

Heatsink

Display

Display

Dual display supported

1 x VGA

1 x 24-bit TTL

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

0°C ~ 60°C

Expansion Slots

Expansion Slots

1 x PCI-104

I/O Interface

Ethernet

10/100Mbps LAN by Realtek RTL8100C

I/O Interface

I/O Interface

1 x LPT

2 x USB 2.0

1 x RS-422/485

2 x RS-232

Power

Power consumption

5V@1.13A (AMD Geode™ LX 800 with one 1 GB 400 MHz DDR memory)

Storage

Storage

1 x IDE

1 x CF Type II

System

Chipset

AMD CS5536

CPU

AMD Geode™ LX 800 (500 MHz) processor

Memory Max.

One 200-pin 400 MHz DDR SDRAM SO-DIMM supports up to 1 GB

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
