Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

Triple independent display

2 x HDMI (up to 4096x2160@24Hz)

1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (with SIM holder & mSATA support)

1 x Half-size PCIe Mini card slot

I/O Interface

Audio

Realtek ALC662 HD codec 1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219-LM PHY with Intel® AMT 11.0 supported

LAN2: Intel® I211-AT PCIe GbE controller

I/O Interface

I/O Interface

4 x USB 3.0

3 x Internal USB 2.0

Power

Power consumption

12V@2.48A (Intel® Core™ i3-6100U CPU with two 8 GB memory)

Storage

Storage

1 x 8 GB eMMC (optional)

2 x SATA 6G/s with 5V SATA power connector (RAID 0,1)

System

CPU

6th generation Intel® mobile ULT on-board SoC

Intel® Core™ i7-6600U (up to 3.4GHz, dual-core, 4MB cache, TDP=15W)

Intel® Core™ i5-6300U (up to 3.0GHz, dual-core, 3MB cache, TDP=15W)

Intel® Core™ i3-6100U (up to 2.3GHz, dual-core, 3MB cache, TDP=15W)

Intel® Celeron® processor 3955U (up to 2.0GHz, dual-core, 2MB cache, TDP=15W)

Memory Max.

Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs (system max.

32 GB)

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
