Spec Item

Description

CPU Cooler

CPU Cooler

CF-989A-RS-R12 / CF-989B-RS

Display

Display

Dual display supported 1 x DVI-I 2 x HDMI 1 x 24-bit dual-channel LVDS

Environment

Humidity

5% ~ 95% non-condensing

Operating Temperature

-10°C ~ 60°C (14°F ~ 140°F)

Expansion Slots

Expansion Slots

1 x PCIe Mini card slot with

mSATA support

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

LAN1: Intel® 82583V PCIe controller

LAN2: Intel® 82579 PHY with Intel® AMT 8.0 supported

I/O Interface

2 x RS-232

1 x RS-422/485

4 x USB 3.0

2 x USB 2.0

1 x 4-pin wafer for SMBus

1 x 4-pin wafer for I²C

1 x 5-pin header for infrared

1 x PS/2 KB/MS

1 x TPM connector (2x10 pin)

I/O Interface

I/O Interface

2 x USB 2.0

4 x USB 3.0

2 x RS-232

1 x RS-422/485

Option

iRIS

N/A

Power

Power consumption

12V@4.89A (Intel® 1.8GHz CPU with 1333MHz DDR3 4GB memory)

Storage

Storage

2 x SATA 6Gb/s

System

Chipset

Intel® QM77

CPU

Intel® Core™ i7/i5/i3, Celeron® Mobile processor

CPU Socket

Socket G2

Memory Max.

1 x 204-pin 1600/1333MHz DDR3 SO-DIMM (system max. 8GB)

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
