Spec Item

Description

Display

Display

Dual display supported

VGA (up to 2048x1536@75Hz)

HDMI (up to 1920x1200@60Hz)

18/24-bit dual-channel LVDS (up to 1920x1200@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-10°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot

1 x PCI-104 slot (PCI signal)

Form factor

Form factor

EPIC

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

Dual LAN: Realtek RTL8111E PCIe GbE controller with ASF 2.0 support

I/O Interface

I/O Interface

4 x USB 2.0

4 x Internal USB 2.0

2 x Internal RS-232

1 x Internal RS-422/485

Power

Power consumption

12V@4.85A (2.6GHz Intel® Core i5-2540M with 1333 MHz 4 GB DDR3 memory)

Storage

Storage

2 x SATA 6Gb/s with 5V SATA power connector

System

Chipset

Intel® HM65

CPU Socket

Socket G2 for 2nd generation Intel® Core™ i7/i5/i3 and Celeron® mobile processor

Memory Max.

One 204-pin 1066/1333 MHz DDR3 SDRAM SO-DIMM slot supports up to 8 GB

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
