Spec Item

Description

BIOS

BIOS

AMI UEFI BIOS

Dimensions

Dimensions

338 mm x 122 mm

Display

Display Output

1 x VGA (up to 1920x1200@60Hz)

1 x 18/24-bit dual-channel LVDS (up to 1920x1200@60Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 2560x1600@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Storage Temperature

-30°C ~ 70°C

Expansion Slots

Expansion Slots

1 x Full/Half-size PCIe Mini card slot PCI and ISA signal via golden finger

I/O Interface

Audio

7.1 channel HD Audio supported by IEI AC-KIT-892HD kit

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I211-AT PCIe controller

LAN2: Intel® I211-AT PCIe controller

Expansion

1 x Full/Half-size PCIe Mini card slot PCI and ISA signal via golden finger

I²C

1 x I²C (1x4 pin)

I/O Interface

I/O Interface

1 x Expansion(Full/Half-size PCIe Mini card slot, PCI and ISA signal via golden finger)

1 x Front panel(2x7 pin, Power LED, HDD LED, Speaker, Power Button, Reset Button)

1 x I²C(1x4 pin)

4 x Internal RS-232(2x5 pin, P=2.54)

2 x Internal RS-232/422/485(2x5 pin, P=2.54)

4 x Internal USB 2.0(2x5 pin, P=2.54)

1 x KB/MS(1x6 pin)

1 x LPT(2x13 pin)

1 x SMBus(1x4 pin)

1 x USB 2.0(180º Type-A)

Power

Power consumption

3.3V@0.009A, 5V@4.68A, 5Vsb@0.008A, 12V@1.143A (Intel® Celeron® J1900 1.99 GHz 10W CPU with 8GB 1600MHz DDR3L memory)

Power Supply

5V/12V, AT/ATX support

Storage

Storage

1 x CF Type II

1 x mSATA (SATA 3Gb/s)

2 x SATA 3Gb/s

System

CPU

Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB cache, TDP=10W)

Intel® Celeron® N2807 on-board SoC (1.58GHz, dual-core, 2MB cache, TDP=4.3W)

Graphcis Controller

Intel® HD Graphics Gen 7 Engines with 4 execution units, supports DX11.1, OpenGL 4.2 and OpenCL1.2

Memory Max.

One 204-pin 1333/1066MHz dual-channel DDR3L SDRAM unbuffered DIMM supports up to 8GB (J1900) or 4GB (N2807)

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset

Weight

Weight

GW: 1000g / NW: 260g
