Part Number

IPC-610BP-00FEE

IPC-610BP-30FEE

IPC-610MB-00FEE

IPC-610MB-30FEE

Form Factor

组装系统

组装系统

Form Factor

4U Rackmount

4U Rackmount

4U Rackmount

4U Rackmount

Front I/O Interface

USB2.0

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

PS/2

1

1

1

1

Cooling

Air Filter

Yes

Yes

Yes

Yes

Fan

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Operating Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

2 G

2 G

Physical Characteristics

Weight

16.2 kg (35.6 lb)

16.2 kg (35.6 lb)

16.2 kg (35.6 lb)

16.2 kg (35.6 lb)

Dimensions (W x H x D)

MB 482 x 177 x 499 mm (19" x 7" x 19.6) / BP 482 x 177 x 449 ( 19" x 7" x 17.8")

MB 482 x 177 x 499 mm (19" x 7" x 19.6) / BP 482 x 177 x 449 ( 19" x 7" x 17.8")

MB 482 x 177 x 499 mm (19" x 7" x 19.6) / BP 482 x 177 x 449 ( 19" x 7" x 17.8")

MB 482 x 177 x 499 mm (19" x 7" x 19.6) / BP 482 x 177 x 449 ( 19" x 7" x 17.8")

Disk Drive Bay

5.25 External Bay

3

3

3

3

3.5 Internal Bay

1

1

1

1

3.5" External Bay

1

1

1

1

Miscellaneous

LED Indicators

Power, HDD and keyboard lock

Power, HDD and keyboard lock

Power, HDD and keyboard lock

Power, HDD and keyboard lock

Power Supply

Power Supply

-

300W (Single)

-

300W (Single)
