Part Number |
ACP-4020BP-25ZE |
ACP-4020BP-30ZE |
ACP-4020BP-40ZE |
ACP-4020MB-25ZE |
ACP-4020MB-30ZE |
ACP-4020MB-40ZE |
Form Factor |
||||||
Form Factor |
4U Rackmount |
4U Rackmount |
4U Rackmount |
4U Rackmount |
4U Rackmount |
4U Rackmount |
Cooling |
||||||
Air Filter |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
Fan |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
System Fan |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
Front I/O Interface |
||||||
USB3.0 |
2 |
2 |
2 |
2 |
2 |
2 |
Environment |
||||||
Operating-Temperature |
0 ~ 45 |
0 ~ 45 |
0 ~ 45 |
0 ~ 45 |
0 ~ 45 |
0 ~ 45 |
Non-Operational Temperature |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
Operating Shock |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
Non-Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
Operating Vibration (5 ~ 500 Hz) |
1 Grms |
1 Grms |
1 Grms |
1 Grms |
1 Grms |
1 Grms |
Non-Operating Vibration (5 ~ 500 Hz) |
2 G |
2 G |
2 G |
2 G |
2 G |
2 G |
Physical Characteristics |
||||||
Weight |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
Dimensions (W x H x D) |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
Disk Drive Bay |
||||||
Slim ODD |
1 |
1 |
1 |
1 |
1 |
1 |
2.5" Internal |
2 |
2 |
2 |
2 |
2 |
2 |
3.5 External Bay |
1 |
1 |
1 |
1 |
1 |
1 |
Miscellaneous |
||||||
LED Indicators |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Rear Panel |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
Intelligent System Module |
||||||
Remote Monitoring |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
Power Supply |
||||||
Power Supply |
250W (Single) |
300W (Single) |
400W (Single) |
250W (Single) |
300W (Single) |
400W (Single) |
