Part Number

HPC-8212SA-R5A1E

HPC-8212SE-R6A1E

HPC-8212SE-R8A1E

Disk Drive Bay

3.5"/2.5" Front-Accessible

12

12

12

2.5” External

-(Rear)

2(Hot Swap)

-(Rear)

Cooling

System Fan

4 (8038) PWM fans

4 (8038) PWM fans

4 (8038) PWM fans

Air Filter

-

-

-

Rear I/O Interface

USB2.0

2

2

2

Miscellaneous

LED Indicators

Power, HDD, LAN1, LAN2, System Information

Power, HDD, LAN1, LAN2, System Information

Power, HDD, LAN1, LAN2, System Information

Environment

Operating Temperature

0 ~ 35° C (32 ~ 95° F)

0 ~ 35° C (32 ~ 95° F)

0 ~ 35° C (32 ~ 95° F)

Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

0.25 Grms

0.25 Grms

0.25 Grms

Non-Operational Temperature

-40 ~ 70° C (-40 ~ 158° F)

-40 ~ 70° C (-40 ~ 158° F)

-40 ~ 70° C (-40 ~ 158° F)

Non-Operating Humidity

10 ~ 95% @ 60° C, non-condensing

10 ~ 95% @ 60° C, non-condensing

10 ~ 95% @ 60° C, non-condensing

Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

2 G

Physical Characteristics

Dimensions (W x H x D)

438 x 88.4 x 540 mm (17.24" x 3.48" x 21.26")

438 x 88.4 x 620 mm (17.24" x 3.48" x 24.41")

438 x 88.4 x 620 mm (17.24" x 3.48" x 24.41")

Power Supply

Power Supply

550W

650W

800W
