Part Number

HPC-7140-00A1E

HPC-7140-R4A1E

Physical Characteristics

Dimensions (W x H x D)

437 x 43 x 504 mm (17.2" x 1.7" x 19.85")

437 x 43 x 504 mm (17.2" x 1.7" x 19.85")

Miscellaneous

LED Indicators

Power, HDD, LAN1, LAN2, System Information

Power, HDD, LAN1, LAN2, System Information

Environment

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Vibration (5 ~ 500 Hz)

0.5 Grms

0.5 Grms

Operating-Temperature

0 ~ 35° C (32 ~ 95° F)

0 ~ 35° C (32 ~ 95° F)

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Vibration (5 ~ 500 Hz)

0.25 Grms

0.25 Grms

Non-Operational Temperature

-40 ~ 70° C (-40 ~ 158° F)

-40 ~ 70° C (-40 ~ 158° F)

Cooling

System Fan

4 (4cm / 23 CFM)

4 (4cm / 23 CFM)

Drive Bay

Hot Swap External

4 (3.5")

4 (3.5")

Slim Optical Drive External

1

1

Expansion Slots

PCIE

1 x PCIe x16

1 x PCIe x16

Front I/O Interface

COM Port

1

1

USB2.0

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables
