Part Number

AIMC-3200-00A1E

Form Factor

Form Factor

Wallmount

Processor System

CPU

Intel Core i3/i5/i7 (LGA1155 socket)

CPU TDP

Up to 95 W

Frequency

Up to 3.4 GHz

Core Number

4

L3 Cache

8 MB

BIOS

AMI SPI 64 Mbit

Chipset

Intel H61

Integrated Graphics

Yes

Memory

Technology

DDR3 1333 MHz

Capacity

Up to 16 GB (8 GB per DIMM)

ECC Support

-

Socket

2 x 204-pin SODIMM

Display

Controller

Intel HD graphics Integrated

Graphic Memory

-

Multiple Display

Dual

Expansion Interface

PCI Express x 16

1

PCI Express x 4

1

PCI Express x 1

-

Mini PCIe

-

Ethernet

Controller

LAN1: Intel 82579V LAN2: Intel 82583V

Speed

10/100/1000 Mbps

Connector

2 x RJ45

WatchDog Timer

Output

System Reset

Interval

Programmable 1~255 sec

Storage

CFast

-

Front I/O Interface

Display

2

LAN

2

USB3.0

-

USB2.0

3

COM

2

PS/2

1 (1 x Keyboard or 1 x Mouse)

Audio

-

Rear I/O Interface

Display

-

LAN

-

USB2.0

-

COM

-

PS/2

-

DVI

-

Ethernet

-

VGA

-

Power Supply

Power Type

ATX

Output Wattage

250W

Input Range

AC 100 V ~ 240 V

Cooling

System Fan

2 (6cm / 27.7 CFM)

Air Filter

Yes

Environment

Operating-Temperature

0 ~ 40° C (32 ~ 104° F) (Operational humidity: 40° C @ 85% RH Non-Condensing)

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F) and 40° C @ 95% RH Non-Condensing

Operating Vibration

1 Grms

Non-Operating Vibration

2 Grms

Operating Shock

10 G

Physical Characteristics

Weight

4.5 kg (9.9 lb)

Dimensions (W x H x D)

232 x 90 x 232 mm (9.1 x 3.5 x 9.1

Certification

EMC

CE/FCC Class A, CCC, BSMI

Safety Certifications

UL, CB, CCC, BSMI

Disk Drive Bay

3.5" Internal

-

2.5" Internal

2

Miscellaneous

LED Indicators

Power, HDD, temperature

Control

Power Switch

Management Solution

Software

SUSIAccess
