Part Number

AIIS-5410P-S9A1E

AIIS-5410P-U0A1E

Expansions

Mini-PCIe

1

1

PCIe x8

1

1

Front I/O Interface

Audio

2 (Min-in, Line-out)

2 (Min-in, Line-out)

Display

1 VGA + 1 DVI

1 VGA + 1 DVI

USB3.0

8

8

Power Requirement

Input Voltage

9 - 36VDC

9 - 36VDC

Power Type

AT/ATX

AT/ATX

Rear I/O Interface

GPIO

8bit

8bit

Series port

2

2

Storage

m-SATA

1

1

CFast

1

1

HDD

2 x 2.5' HDD Bay

2 x 2.5' HDD Bay

Processor System

CPU

i5-6442EQ

i7-6822EQ

Frequency

1.9GHz

2.0 GHz

L3 Cache

6 MB

8 MB

BIOS

AMI 64 Mb SPI Flash

AMI 64 Mb SPI Flash

Chipset

QM170

QM170

Camera Interface

Ports

4

4

Technology

PoE

PoE

Environment

Operating Vibration

1Grms (with HDD), 3Grms (with SSD)

1Grms (with HDD), 3Grms (with SSD)

Operating-Temperature

SSD : -20 ~ 60° C with 0.7m/S air flow ; With HDD :20 ~ 60° C with 0.7m/S air flow; HDD :0 ~ 40° C with 0.7m/S air flow ; With HDD :20 ~ 60° C with 0.7m/S air flow

SSD : -20 ~ 60° C with 0.7m/S air flow ; With HDD :20 ~ 60° C with 0.7m/S air flow; HDD :0 ~ 40° C with 0.7m/S air flow ; With HDD :20 ~ 60° C with 0.7m/S air flow

Ethernet

Controller

Intel i210AT

Intel i210AT

Graphics

Chipset Integrated

Intel HD Graphic 530, support DirectX12

Intel HD Graphic 530, support DirectX12

Memory

Max. Capacity

32GB (Up to 16GB each)

32GB (Up to 16GB each)

Socket

2 x 260-pin SO-DIMM

2 x 260-pin SO-DIMM

Technology

DDR4 2133/1866 MHz

DDR4 2133/1866 MHz

Miscellaneous

Control

Power on/off switch

Power on/off switch

LED Indicators

Power, HDD, Temperature, PoE LED

Power, HDD, Temperature, PoE LED

Physical Characteristics

Dimensions (W x H x D)

235x88x188mm

235x88x188mm

Weight

2.9kg (6,39lbs)

2.9kg (6,39lbs)

WatchDog Timer

Interval

Programmable 1 ~ 255 sec/min

Programmable 1 ~ 255 sec/min

Output

System Reset

System Reset
