处理器

CPU

6/7th Generation Intel® Core™ Processors, LGA 1151 Socket

网络

1*Intel® I211AT PCIe (10/100/1000Mbps)

4*Intel® I210IT PCIe (10/100/1000Mbps)

1*Intel® I219V with iAMT11.0 PCIe (10/100/1000Mbps) (only Core i7/i5 supports iAMT)

内存

2*260-pin SODIMM up to 32GB Dual Channel DDR4 1866/2133MHz

显示

Triple Displays

1*HDMI HDMI: resolution up to 4096x2160 @ 24Hz or 2560x1600 @60Hz

1*DP DP:resolution up to 4096x2304 @ 60Hz

1*VGA VGA: resolution up to 1920x1200 @ 60Hz

1*DVI DVI: resolution up to 2560x1600 @ 60Hz

储存

2*2.5" SATA 3.0 Drive Bay (RAID 0/1)

串口

2*RS-232/422/485 (DB-9) (RS-232 with power)

1*RS-232/422/485 (DB-9)

USB

4*USB 3.0 (type A)

DIO

1*16-bit DIO

扩展插槽

1*Full-size Mini PCIe (PCIe/USB)

1*Half-size Mini PCIe (USB/mSATA)

1*PCIe x16

电源

9~36V DC-in

外形尺寸

235mm x 102.5mm x 222mm (W x H x D)

工作环境

Temperature

工作温度:0~50°C (SSD or mSATA-mini, with 0.7m/s air flow)

存储温度：-20°C~85°C

安装方式

Wall Mount Kit, RoHS
