Part Number

WOP-3120T-C4AE

Communications

I/Os

USB 2.0 Client x 1, USB 2.0 Host x 1 (Top), Micro-SD Slot, Audio 1 Line-out / 1 Mic-in

COM1

RS-232/RS-422/RS-485 (DB9)

COM2

RS-422/RS-485 (Terminal 4pin+Ground)

COM3

RS-485 (Terminal Plug 2-Pin)

CAN

Terminal Plug 2-Pin

Ethernet

10/100-BaseT

General

Certifications

CE, BSMI, CCC, UL 61010, FCC Class A

Dimensions

311 x 237 x 46.8 mm (12.24" x 9.33" x 1.84")

Cut-out Dimensions

302.5 x 228.5 mm (12.1" x 9.14")

OS Support

Microsoft® Windows WES7 32bit/64bit /WE8S 64bit /Windows 7 32bit/64bit / Windows 8 64 bit / Linux Kernel

Power Input

24VDC ±10%

Power Consumption

12 W

Enclosure Housing

PC + ABS

Mounting

Panel

Weight (Net)

2.5 kg (5.51 lbs)

System Hardware

CPU

RISC 32 bits, 600 MHz (ARM® Cortex™-A8)

Battery Backup Memory

FRAM 1M bit (=128K Byte, 64word

Flash Memory

DDR2 256MB on board

Storage

512MB on board SLC type

Power-On LED

Yes

LCD Display

Display Type

XGA TFT LED LCD

Max. Resolution

1024 x 768

Max. Colors

64K

Luminance (cd/m2)

500

Backlight Life

LED, 50,000

Viewing Angle (H/V°)

160/140

Dimming

Adjustable by touch panel

Contrast Ratio

500 : 1

Display

Size

12"

Touchscreen

Lifespan

36 million touches at 8mm-diameter finger poin through silicone rubber bearing at least 250g 2 times per second.

Light Transmission

Transmission Above 80%

Resolution

Linearity

Touch Type

5-wire, analog resistive

Environment

Temperature (Operating)

-20 ~ 60°C (-4 ~ 140°F)

Temperature (Storage)

-30 ~ 70° C (-22 ~ 158° F)

Humidity (Operating)

10 ~ 90% RH @ 40°C, non-condensing

Ingress Protection

Front panel: IP66

Vibration Protection

Operating, radom vibration 1 Grms (5 ~ 500 Hz)
