Part Number

WOP-3070T-C4BE

General

Certifications

BSMI, CCC, CE, FCC Class A, UL

Dimensions

203.4 x 150 x 43.7 mm (8.01" x 5.91" x 1.72")

Cut-out Dimensions

192 x 138.5 mm (7.56" x 5.45")

OS Support

Microsoft® Windows CE 6.0

Power Input

24VDC ±10%

Power Consumption

7W (Typical)

Enclosure Housing

PC + ABS

Mounting

Panel

Weight (Net)

1 Kg (2.20 lbs)

System Hardware

CPU

RISC 32 bits, 600 MHz (ARM® Cortex™-A8)

Battery Backup Memory

FRAM 128KB

Flash Memory

DDR2 256MB on board

Storage

512MB on board SLC type

Power-On LED

Yes

Communications

COM1

RS-232/422/485 (DB9 Male)

COM2

RS-422/485 (Terminal Plug 4-Pin)

COM3

RS-485 (Terminal Plug 2-Pin)

CAN

Terminal Plug 2-Pin

Ethernet

10/100-BaseT

LCD Display

Display Type

WVGA TFT LCD

Max. Resolution

800 x 480

Max. Colors

64K

Luminance (cd/m2)

500

Viewing Angle (H/V°)

140/120

Backlight Life

LED, 50,000

Dimming

Adjustable by touch panel

Contrast Ratio

700:1

Display

Size

7

Touchscreen

Lifespan

36 million touches at 8mm-diameter finger point

Light Transmission

Transmission Above 80%

Resolution

Linearity

Touch Type

5-wire, analog resistive

Environment

Temperature (Operating)

-20 ~ 60°C (-4 ~ 140°F)

Temperature (Storage)

-30 ~ 70°C (-22 ~ 158°F)

Humidity (Operating)

10 ~ 90% RH @ 40°C, non-condensing

Ingress Protection

Front panel: IP66

Vibration Protection

Operating, radom vibration 1 Grms (5 ~ 500 Hz)
