Part Number

TPC-1881WP-433AE

TPC-1881WP-473AE

Display

Size

18.5"

18.5"

General

Power Consumption

28W Typical, 60W Max. (Without Add-on card)

28W Typical, 60W Max. (Without Add-on card)

Power Input

24VDC +/- 20%

24VDC +/- 20%

Watchdog Timer

1 ~ 255 sec (system)

1 ~ 255 sec (system)

Mounting

Panel Mount

Panel Mount

Certifications

BSMI, CCC, CE, FCC Class A, UL

BSMI, CCC, CE, FCC Class A, UL

BIOS

AMI UEFI

AMI UEFI

Cooling System

Fanless design

Fanless design

OS Support

Microsoft® Windows WES7 32bit/64bit /WE8S 64bit/ Windows 7 32bit/64bit / Windows 8 64bit/Ubuntu 14.04.2 LTS/Windows 10 IoT Enterprise LTSB

Microsoft® Windows WES7 32bit/64bit /WE8S 64bit/ Windows 7 32bit/64bit / Windows 8 64bit/Ubuntu 14.04.2 LTS/Windows 10 IoT Enterprise LTSB

Weight (Net)

7kg (15.44 lbs)

Enclosure Housing

Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin

Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin

Dimensions

488 x 309 x 56.7 mm (19.21" x 12.17" x 2.23")

488 x 309 x 56.7 mm (19.21" x 12.17" x 2.23")

System Hardware

CPU

Intel 4th Generation Core i3-4010U 1.7GHz

Intel 4th Generation Core i7-4650U 1.7GHz

Memory

4GB DDR3L 1600MHz SO-DIMM SDRAM

4GB DDR3L 1600MHz SO-DIMM SDRAM

Storage

CFast slot x 1, 2.5" SATA SSD slot x 1, mSATA slot x 1 (via Mini PCIe slot, can't be used simultaneously with iDoor)

CFast slot x 1, 2.5" SATA SSD slot x 1, mSATA slot x 1 (via Mini PCIe slot, can't be used simultaneously with iDoor)

Chipset

Lynx Point-LP

LAN

10/100/1000Base-T x 2

10/100/1000Base-T x 2

Expansion Slots

Full-sized Mini PCI-E x 1

Full-sized Mini PCI-E x 1

I/O

RS-232 x 1, RS-232/422/485 x 1, USB 3.0 x 2, HDMI 1.4 x 1, Audio Line out x 1, USB 2.0 x 1 (optional), Audio MIC x 1 (optional)

RS-232 x 1, RS-232/422/485 x 1, USB 3.0 x 2, HDMI 1.4 x 1, Audio Line out x 1, USB 2.0 x 1 (optional), Audio MIC x 1 (optional)

LCD Display

Viewing Angle (H/V°)

170/160

Luminance (cd/m2)

300

Contrast Ratio

500 : 1

Max. Resolution

1366 x 768

Max. Colors

16.7 M

Display Type

HD TFT LED LCD

Backlight Life

50,000 hrs

Environment

Ingress Protection

Front panel: IP66

Front panel: IP66

Vibration Protection

With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

Operating Temperature

0 ~ 55°C (32 ~ 131°F)

0 ~ 55°C (32 ~ 131°F)

Storage Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Humidity

10 ~ 95% RH @ 40°C, non-condensing

10 ~ 95% RH @ 40°C, non-condensing

Touchscreen

Light Transmission

=88%

=88%

Resolution

4096 x 4096 dot

4096 x 4096 dot

Type

Projected capacitive

Projected capacitive
