Part Number

PPC-3170-RE4BE

Processor System

CPU

Intel® Atom™ E3845, Quad core

Frequency

1.91GHz

L3 Cache

2M

Memory

1 x SO-DIMM, DDR3L 1333MHz,Max 8 GB

Storage

1 x 2.5" SATA Bay, 1 x mSATA Bay

Network (LAN)

2 x 10/100/1000 Mbps Ethernet (Intel I210)

I/O Ports

1 x isolated RS-422/485 (terminal block) 4 x RS-232, two external and two by internal pin header (need optional module), 1 x GPIO (8 channels, TTL level) by internal pin header (need optional module), 1 x USB3.0 + 3 x USB2.0, 1 x D-SUB VGA port, 1 x DP1.1a, 1 x Line-out, 1 x Mic-in

Expansion Slots

1 x Mini PCIe;1 x PCIe x4 or PCI;Optional: 1 x Cfast, 1 x CF card, 1 x internal USB dongle, 2 x RS-232 or 1 x RS-232 + 1 x GPIO

Speaker

2 x 1W

Watchdog Timer

Watchdog Timer

255 timer levels, set up by software

Physical Characteristics

Dimensions

437 x 357 x 56.5 mm (17.2 x 14.0 x 2.22 in)

Weight

6.3 Kg (13.89lb)

OS Support

OS Support

Microsoft® Windows 7/8.1/10 (32/64-bit), WES7, Linux

Power Supply

Input Voltage

9-32 VDC

Power Consumption

34W (Burn-in test 7.0 in Windows 7 32 bit)

Display

Display Type

17" TFT LED Panel

Max. Resolution

1280 x 1024

Viewing Angle

80 (left), 80 (right), 60 (up), 80 (down)

Luminance (cd/m2)

350

Backlight Life (hrs)

50, 000 hrs (Min.)

Touchscreen

Touch Type

Analog Resistive 5-wire

Light Transmission

81+/-3%

Controller

USB interface

Durability (Touches)

36 million

Environment

Operating Temperature

0 ~ 50 °C (32 ~ 122 °F) with 2.5" SATA SSD;-20 ~ 60 °C (-4 ~ 140 °F) with -40 ~ 85 °C mSATA or 2.5" SATA SSD

Storage Temperature

-40 ~ 60°C (-40~140°F)

Relative Humidity

10 ~ 95% @ 40° C (non-condensing)

Shock Protection

Operating 10 G peak acceleration (11 ms duration), follow IEC 60068-2-27

Vibration Protection

Operating Random Vibration Test 5~500Hz, 1Grms @with HDD, follow IEC 60068-2-64

EMC

BSMI,CE,FCC,Class A

Safety

CB, CCC, BSMI, UL

Front Panel Protection

IP65 Compliant
