Part Number

ARK-6322-Q0A2E

Processor

CPU

Intel Celeron Processor J1900 Quad Core

Core Number

4

Max Speed

2.0 GHz, Turbo Boost up to 2.41GHz

L2 Cache

2 MB

BIOS

AMI 16 Mbit SPI (Default BIOS is supported for 64-bit OS installation, BIOS for 32-bit OS is supported by project)

Memory

Technology

Dual channel DDR3L 1333MHz SDRAM

Max. Capacity

8 GB, 4 GB per SO-DIMM

Socket

2 x 204-pin SO-DIMM

Graphics

Controller

Intel Gen 7 Graphics Engines and media encode/decode engine; GPU Frequency: 688 MHz

VRAM

Shared system memory up to 224 MB SDRAM

VGA

Supports up to 2048 x 1280

Display port

Supports resolution up to 2560 x 1600

Dual Display

VGA+DP

Ethernet

LAN1

10/100/1000 Mbps RTL8111E GbE

LAN2

10/100/1000 Mbps RTL8111E GbE

Audio

Interface

Realtek ALC892, High Definition Audio, Line-out, Mic-in

I/O Interface

Serial Port

5 x RS-232 ports, 1 x RS-232/422/485 with auto flow control (COM3)

USB

1 x USB 3.0 port and 7 x USB 2.0 ports

Other

Watchdog Timer

255 levels timer interval, setup by software

Digital IO

8-bit programmable (Reserved)

Expansion

Mini PCIe

1 x Full-size Mini PCIe, support mSATA storage or WWAN module; 1 x Half-size Mini PCIe, support WLAN module

Storage

HDD

1 x SATA HDD Bay for 2.5" or 3.5" device with maximum height 26.1mm

Solid State Disk

1 x mSATA share with mini-PCIe slot

Software Support

Microsoft Windows

Windows 10, Windows 8 , Windows 7, WES8, WES7

Linux

Support (by Project)

Power

Power Type

ATX

Input Voltage

12 VDC, ± 10%

Power Adaptor

AC to DC, DC12V/5A, 60 W (Optional)

Consumption

Typical 15.7 W, Max. 24.7 W

Mechanical

Construction

Aluminum housing

Mounting

Wall mounting kit (optional), VESA mounting kit (optional)

Dimensions

200 x 64 x 200 mm

Weight

2.0 kg

Environment

Operating Temperature

With extended temperature peripherals/SSD: 0 ~ 50° C (32 ~ 122° F) with 0.7 m/s air flow, With 3.5-inch hard disk 0 ~ 40° C (32 ~ 104° F) with 0.7 m/s air flow, With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7 m/s air flow

Storage Temperature

-40 ~ 85° C (-40 ~ 185° F)

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With HDD: 0.5 Grms, IEC 60068-2-64, random, 5~500Hz, 3 axes, 1hr/axis

Shock During Operation

With HDD: 10 G, IEC 60068-2-27, half sine, 11 ms duration

EMC

CE/FCC Class A, CCC, BSMI

Safety Certifications

CB, UL, CCC, BSMI
