Processor

ARK-2150F-S7A1E

CPU

Intel ULV 3rd Gen Core i7 3517UE

Core Number

2

Frequency

Dual Core 1.7 GHz (Max Turbo Frequency 2.8 GHz)

L3 Cache

4 MB

Chipset

Intel QM77

BIOS

AMI EFI 64Mbit

Memory

Technology

DDR3 1600MHz,DDR3L 1333 MHz

Max. Capacity

8 GB

Socket

1 x 204-pin SODIMM

Graphics

Chipset

Intel QM77 Integrated GFX Gen 7

Graphic Engine

DirectX11, OpenGL 3.1, and Open CL 11; Hardware decode acceleration: AVC/H.264, MPEG-2, VC-1

VGA

Integrated 340.4MHz RAMDAC, Max resolution up to 2048 x 1536 @ 75Hz

HDMI

Supports HDMI 1.4 for HD Video playback (no hotplug support); Max resolution up to 2560 x 1600 @ 60Hz on DisplayPort, Max resolution up to 1920 x 1200 @ 60Hz on HDMI

DVI-D

Max resolution up to 1920 x 1200

Dual Display

Yes, VGA+HDMI/DisplayPort, VGA+HDMI/DVI-D, VGA+DVI-D, HDMI/DisplayPort+DVI-D

Ethernet

LAN1

10/100/1000 Mbps Intel 82579LM GbE, support Wake On Lan

LAN2/LAN3/LAN4

10/100/1000 Mbps Intel 82583V GbE

Audio

Interface

Realtek ALC892, High Definition Audio. Line-out,Mic-in,Line-in

I/O Interface

Serial Port

4 x RS-232/422/485 port with auto flow control

USB Interface

3 x USB 3.0 ports and 3 x USB 2.0 ports

Other

Digital IO

4ch digital input and 4ch digital output with 2.5KV isolation

Watchdog Timer

255 levels timer interval, setup by software

Expansion

Mini PCIe

2 x Full-size Mini PCIe (Supports mSATA & SIM); 1 x Half-size Mini PCIe

Storage

HDD

Supports one SATA 2.5" HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 600 MB/s)

SSD

Supports one internal mSATA socket

Software Support

Microsoft Windows

Windows 7, Windows 7 Embedded, XP Professional, XP Embedded

Linux

Ubuntu 12.04

Power

Power Type

AT/ATX

Input Voltage

12 ~ 24 VDC

Power Adaptor

AC to DC, DC19 V/3.42 A, 65 W (Optional)

Consumption

Typical 10.3 Watt, Max. 25.7 Watt

Mechanical

Construction

Aluminum housing

Mounting

Din-Rail mounting, Desk/wall-mounting, VESA mounting

Dimensions

264.5 x 75.1 x 133.0 mm (10.41" x 2.96" x 5.24")

Weight

2.8kg (6.17lb)

Environment

Operational Temperature

With extended temperature peripherals: -20 ~ 60° C (-4 ~ 140° F) with 0.7m/s air flow; With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7m/s air flow

Storage Temperature

-40 ~ 85° C (-40 ~ 185° F)

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With SSD: 5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.

Shock During Operation

With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration

Certification

EMC

CE, FCC Class A, CCC, BSMI

Safety Certifications

UL, CCC, BSMI
